KT-PD

Desk Pneumatic Marking Machine

The KT-PD series uses pneumatic technology – having a precise dot pin for marking. The machine is ideal for materials with hard surfaces, like metals with HRC less 60, such as stainless steel.

Desk Pneumatic Marking Machine

The KT-PD series uses pneumatic technology – having a precise dot pin for marking. The machine is ideal for materials with hard surfaces, like metals with HRC less 60, such as stainless steel.

Pneumatic marking system

Excellent flat surface marking

Hard alloy tungsten pins

Deep and clear marking

ISO9001:2008/CE approved

Customizable

Optional Add-ons for your personalized production

Kuntai Laser offers a wide range of optional accessories for various industrial applications.

Marking Dot Pin

We provide 4 types of short dot pin for various marking depth and mark type needs. Please consult with our sales associate if you are not sure which type you need.

Extended Pin

Extended Pin is used along with V-shaped bracket for a long dot pin marking movement range.

Rotary Module

The rotary module is needed for marking on circular surface.

Foot Pedal

Used to trigger marking operation as a replace for the manual switch.

Plate Holder

Used to fix the position of small metal parts such as tag and nameplate.

Technical Specifications

Machine size330x400x740
The weight of the machine25
Mark range (plane)120mmX80mm/150mmX130mm/200mmX150mm/300mmX200mm
Mark range (circumference)100mm/125mm/160mm/200mm
The depth of marking0.01-2mm(Depending on the material hardness)
Standard speed30-40mm/s
Lift range300mm
The power of the machine500W
Air pressure requirements0.3-0.6Mpa(Industrial / compressed gas source)
power requirementAC 20V/50Hz
Material hardness<=HRC60
system requirementswindows7,10,11

Various industry Applications

Your various industrial needs can be fulfilled by Kuntai Laser’s pro-tested, efficient, and effective product lines

Metal Marking

Pneumatic Marking Machines are great for marking barcodes, serial numbers, codes on metal surfaces with depth.

VIN Marking

LoOur machines are reliable solution for permanent identification on automotive parts and components.

Personalized Solution for your need

Automated prodcution Line Intergration

Branded Product System

Robotic Arm, Machine Visual, etc

Machine System Size Configuration
